Shell connector finite element analysis

Targeted SesamX version: V2020_04

This video tutorial showcases how to use Salome and SesamX to build a shell finite element model and visualize the results. Starting from a shell geometry, it gives practical advice to build the mesh with Salome. Then it covers the mesh import from the Salome .med file into SesamX, and how to finalize the model definition with SesamX. Finally, the last part of this tutorial demonstrates how to visualize the computation results with Salome.
